O20 Boost Configuration
Model		O20 Boost (EPAC)
General Info	Brand Line	ENGWE
	Model	O20 Boost (EPAC)
	Market	UK
	Weight	25kg
	Load weight limit	150kg
	Ride Height	5.0 ft - 6.2ft (155cm-190cm)
	WaterProof	IPX7：Waterproof wire IPX6：Display，Light IPX5：Motor and Controller IPX4：Battery Box
	Terrain	Tarmac roads and bicycle routes; Ways paved by gravel; Soft land: Sand beach/Grass Off-road: Country roads/paved trails
	Pedal Assist	5 level
	Range	Cycling Test 141km -- Pas1 Cycling Test 108km -- Pas3 Cycling Test 80km -- Pas5
	Fold	Yes
	Certification	CE EN15194 by TUV certification
Frameset	Frame style	Compact with fold frame
	Fork	Hydraulic，adjustable Lockout, 50mm travel
	Rear suspension	/
	Frame	6061 Aluminum Alloy with Internal Battery, Step-through
Wheel Set	Tires	20 x 2.125 urban Hybrid tire, anti-puncture
Wheel Set	Wheels	20-inch, 12-gauge, 36-hole, double-wall aluminum, black
Ebike system	Motor	Hub-motor, 48V
	Max torque	75Nm
	Assist	Torque sensor
	Battery	48V, 15Ah, 720Wh, 21700-LG cells, with BMS
	Battery for influencers	48V, 13.5Ah, 648Wh, 21700 cells, with BMS
	Display	3.5' LED color display, ENGWE designed,Mid-position,with Bluetooth
	ENGWE APP	App control available
	Charger	54.6V 4A output, EU/UK voltage available
	Front Light	40lux, with K mark
	Rear Light	with K mark
Brakes	Brake	Hydraulic with double piston
Brakes	Disc rotor	160mm disc Front and Rear
Drivetrain	Chain	C8R8 AntiRust,112 Links
	Chaining	48 tooth
	Crank	170mm
	Rear Derailleur	Shimano Altus 8 Speed，RD-M310
	Shift lever	SHIMANO SL-M315-8R
	Cassette	8 Speed 13T-28T
	Pedals	foldable
Cockpit	Saddle	Soft Saddle by ENGWE
	SeatPost	10 level adjustable
	Handlebars	620mm width
	Stem	Foldable Stem
	Seat Clamp	Quick Release
Accessories	Rear Rack	Included, Max 15kg load
	Kickstand	Center support (included)
	Findmy	Compatible with iOS/Android (included)
	Suspension tube	40mm, available for purchase
